Hougen

HMD2MT Hougen #2 Morse Taper Arbor Mag Drill - 115V

Regular price $2,495.00 CAD
Sale price $2,495.00 CAD Regular price $2,775.00
Save $280.00
SKU: 0200102
Shipping calculated at checkout.

#2 Morse Taper arbor system to use a variety of tooling.

With a #2 Morse Tapor arbor system, the HMD2MT is one of Hougen's most versatile mag drills. Use with "12,000-Series" & Copperhead annular cutters, or quickly change tooling to use drill chucks, taper shank twist drills, reamers, and tap holes with the forward & reverse switch.

  • Max Depth: 2" (50mm)
  • Max Diameter: 7/16" - 1-5/8" (12mm - 41mm)

PLEASE SELECT YOUR MODEL FROM THE DROP-DOWN MENU ABOVE
All drills include: carrying case, pint of coolant, safety chain & hex wrenches.
Fab Kit includes 0200102 drill, chuck adapter, 1/2" drill chuck & 83000 tapping kit.

  • Powerful high torque Hougen motor and gears
  • Two speed gear box - 250 & 450 RPM
  • Forward & reverse switch for tapping
  • Pilot light for low light conditions and greater hole accuracy
  • Double dovetail slide for a stroke up to seven inches
  • Gravity fed coolant bottle
  • Two stage magnet. Engages full power only when motor is turned on which increases magnet life
  • Many accessories are available to turn your drill into a portable machine shop including: drill chucks, tapping, countersink and more
  • Feed handles quickly change from side to side
  • Lift detector safety system
  • Carrying case included (08687)
  • Two year warranty
  • Diameter Range: 7/16" - 1-5/8" (12mm - 41mm)
  • Depth: 2" (50mm)
  • Cutter/Mount: Morse Taper 2, "12,000-Series" & Copperhead cutters, 3/4" shank
  • Twist Drill Capacity: 3/4" w/ drill chuck
  • Reamer Capacity: 3/4" w/ 2MT shank
  • Tapping Capacity: 5/8" w/ 2MT shank

Drill More Holes

Optimize your fab shop with accessories for enhanced drilling performance:
