Hougen

HMD130 Hougen Ultra Low Profile Mag Drill - 115V

Regular price $1,499.00 CAD
Sale price $1,499.00 CAD Regular price $2,021.25
Save $522.25
SKU: 0130101
Shipping calculated at checkout.

Pickup available at Celtic Industrial

Usually ready in 5+ days

HMD130 Hougen Ultra Low Profile Mag Drill - 115V

  • Celtic Industrial

    Pickup available, usually ready in 5+ days

    5736 103A Street Northwest
    Edmonton AB T6H 2J5
    Canada

    +17804310970

UItra low profile lightweight right angle drill with a large capacity for truck frames & general fabrication.

At only 6-11/16" high and lightweight at only 23.8 lbs, the Hougen HMD130 Ultra Low Profile Drill is perfect for hard-to-reach spots you couldn't access with a hand drill, or for horizontal applications. The HMD130 uses RotaLoc Plus Cutters, requiring no tools for installation or removal. A pilot light, high torque gearing, and a lift detector safety system mean you can drill safely and accurately.

  • Max Depth: 1" (50mm)
  • Max Diameter: 7/16" - 1-3/8" (12mm - 35mm)

UItra low profile lightweight right angle drill with a large capacity for truck frames & general fabrication.

  • Only 6-11/16" high for extreme tight spots
  • Lightweight at only 23.8 lbs (10.8 kg)
  • Patented quill feed arbor for smooth cuts and minimal maintenance
  • Uses RotaLoc Plus cutters which require no tools for installation or removal
  • Pilot light for low light conditions and greater hole accuracy
  • Two stage magnet. Engages full power only when motor is turned on, which increases magnet life.
  • Positive slug ejection.
  • High torque gearing
  • Lift detector safety system
  • Feed handle switches easily from side to side
  • Ratchet can be used in place of feed handle
  • Rear-mounted controls
  • Carrying case included (08498)
  • Two-year warranty
Electrical System 115V, 50/60 Hz - 9A, 1035W
Motor 8A (115V)
RPM 450
Diameter 7/16" - 1-3/8" (12mm - 35mm)
Cutter/Mount RotaLoc Plus Cutters
Dimensions 6-15/32" H x 6-3/4" W x 14-11/16" L
Magnet Base 4" W x 9" L
1" Plate Dead Lift 2,165 lb
1" Plate Drillpoint Breakaway 735 lb
3/8" Plate Dead Lift 1,200 lb
3/8" Plate Drillpoint Breakaway 500 lb

Operator's manuals with parts & wiring diagrams for HMD130:


Contact Us for help identifying your tool model & serial number.
